Masuda air breather MSA
Home > Fluid Machinery > Filter > Masuda filter >
 |
◆ Features ● MSA type air breather is widely used in hydraulic equipment such as industrial machinery, machine tool, ship and so on . ● Light alloys are used for the material, and the toughness and durability are outstanding. ● The structure is briefly summarized, disassembled, easy to maintain. ● It is superior in safety because it has a quasi-inflammation prevention structure. |
Model number code
※ - MSA - 60N
┃ ┃ ┃
Special specification model series number
(filter material) (airflow rate)
■ Port size / airflow rate (10μ PVF sheet, pressure loss 1 kPa)
| Type expression |
Connection port diameter R |
Airflow rate L / min |
| MSA-60N | 1/2 | 60 |
| MSA-100N | 3/4 | 100 |
| MSA-250N | 3/4 | 250 |
| MSA-650N | 1 | 650 |
■ Special symbol
| symbol | Element material |
| Nil | Standard product (PVF sheet) |
| S |
Fire service compliant type (stainless steel wire mesh ) |
.
